CVF020L1 - Sauro - 2 poles: 2, clamp tightening, 16A, 2.5mm², 12AWG, 300V, Green

Part number: CVF020L1

Manufacturer: SAURO

Category: Terminal Blocks

In stock: 10000 (Can ship in 24 hours)
1,00

Prodotto aggiunto al carrello.

Vai al carrello

Quantità massima acquistabile per il prodotto raggiunta

Vai al carrello

Spese di spedizione: gratis
Consegna prevista entro Lunedì 04/03

Per il tuo business da Gamma Components, Distributore di componenti elettronici.

  • Product: CVF020L1
  • Series: CVF
  • Description: 2 poles: 2, clamp tightening, 16A, 2.5mm², 12AWG, 300V, Green
  • DC: 1544
  • RoHS compliant: Yes
  • Package: Box
  • HTC: n/a
  • Datasheet

Key Features and Benefits
  • The CVF series female vertical connector allows for the wiring of wires up to 2.5mm² (12 AWG), consequently supporting a current capacity of up to 15A certified.
  • Available in metric pitches of 5 mm (.197 in), 7.5 mm (.295 in), and 10 mm (.394 in) as well as imperial pitches of 5.08 mm (.200 in), 7.62 mm (.300 in), and 10.16 mm (.400 in), in monolithic bodies from 2 to 25 ways, in adjacent, modular, or flanged versions.
  • Featured with an asymmetrical profile that prevents connection errors with the corresponding male connectors CIM, CPM, or CRM soldered to the board or CGM flying type.
  • Modular base connectors can be combined side by side to achieve any number of ways without losing pitch, taking advantage of this feature allows for minimal stock management of base connectors.
Technical Specifications
Pitch 5.00 mm
Gender Female
Wire Connect System Screw
Wire Angle (Degree) 270, Left Side
Wire Sect. Solid / Stranded 2.5/1.5 mm2
